Introducción
Hoy probamos una de las mejores placas base con el socket Z590 para Intel, con un potente VRM de 20+1 fases, botón Dual-Bios y un chip Intel® 2.5GbE LAN AQUANTIA® 10GbE BASE-T LAN , entre otras interesantes características.
Muchísimas gracias a Gigabyte por enviarnos esta placa base Aorus Z590 Xtreme para esta review
AORUS Z590 XTREME: CARACTERISTICAS TECNICAS
CPU Soportadas
11th Generation Intel® Core™ i9 procesadores / Intel® Core™ i7 procesadores / Intel® Core™ i5 procesadores
10th Generation Intel® Core™ i9 procesadores / Intel® Core™ i7 procesadores / Intel® Core™ i5 procesadores / Intel® Core™ i3 procesadores/ Intel® Pentium® procesadores/ Intel® Celeron®
CHIPSET
Intel® Z590 Express Chipset
MEMORIA SOPORTADA
Procesadores Intel 11 Generación Intel® Core™ i9/i7/i5 :
Soporte DDR4 5400 (O.C) / DDR4 5333(O.C.) / DDR4 5133(O.C.) / DDR4 5000(O.C.) / 4933(O.C.) / 4800(O.C.) / 4700(O.C.) / 4600(O.C.) / 4500(O.C.) / 4400(O.C.) / 4300(O.C.) / 4266(O.C.) / 4133(O.C.) / 4000(O.C.) / 3866(O.C.) / 3800(O.C.) / 3733(O.C.) / 3666(O.C.) / 3600(O.C.) / 3466(O.C.) / 3400(O.C.) / 3333(O.C.) / 3300(O.C.) / 3200 / 3000 / 2933 / 2800 / 2666 / 2400 / 2133 MHz
Procesadores Intel 10 Genración Intel® Core™ i9/i7 processors
Soporte DDR4 2933/2666/2400/2133 MHz memory modules
Procesadores 10 Generación Intel® Core™ i5/i3/Pentium® /Celeron® :
SoporteDDR4 2666/2400/2133 MHz
4 x DDR4 DIMM , hasta 128 GB DDR4 con soporte para memoria Doble-Canal.
Soporte para memoria ECC y Extreme Memory Profile ( XMP)
AUDIO
Realtek® ALC1220-VB codec+ESS ES9018K2M DAC+TI OPA1622
Soporte para DTS:X® Ultra
High Definition Audio
2/4/5.1/7.1-channel
Soporte S/PDIF Out
LAN
1 x Aquantia 10GbE LAN chip (10 Gbit/5 Gbit/2.5 Gbit/1 Gbit/100 Mbit) (LAN1)
1 x Intel® 2.5GbE LAN chip (2.5 Gbit/1 Gbit/100 Mbit) (LAN2)
WIRELESS
Intel® Wi-Fi 6E AX210
SLOTS EXPANSION
1 x PCI Express x16 slot, x16 (PCIEX16)
1 x PCI Express x16 slot, x8 (PCIEX8)
1 x PCI Express x16 slot, x4 (PCIEX4)
INTERFAZ ALMACENAMIENTO
CPU:
1 x M.2 connector (Socket 3, M key, tipo 2242/2280/22110 PCIe 4.0 x4/x2 SSD ) (M2P_CPU)*
* Solo compatible procesadores Intel 11 Generación.
Chipset:
1 x M.2 connector (Socket 3, M key, tipo 2242/2280/22110 SATA and PCIe 3.0 x4/x2 SSD ) (M2A_SB)
1 x M.2 connector (Socket 3, M key, tipo 2242/2260/2280/22110 SATA and PCIe 3.0 x4/x2 SSD soporte) (M2M_SB)
6 x SATA 6Gb/s conectores
Soporte RAID 0, RAID 1, RAID 5, y RAID 10
Intel® Optane™ Memory Ready
